The Sony STR-DH590 is a 5.2 channel AV receiver designed for home theaters, offering 145W per channel, 4K/HDR support, Bluetooth, and HDMI connectivity. This manual guides setup, features, and troubleshooting.
1.1 Overview of the Receiver
The Sony STR-DH590 is a 5.2-channel AV receiver designed for immersive home theater experiences. It supports 4K and HDR formats, including Dolby Vision and HDR10, and features four HDMI inputs for seamless connectivity. The receiver also includes Bluetooth for wireless audio streaming and compatibility with high-resolution audio formats like Dolby TrueHD and DTS-HD Master Audio, ensuring versatile and high-quality sound performance.
1;2 Importance of the Manual
The manual is essential for understanding and optimizing the Sony STR-DH590 receiver’s features and settings. It provides detailed guidance on installation, connectivity, and troubleshooting, ensuring users can fully utilize the receiver’s capabilities. The manual also helps resolve common issues and enhances the overall home theater experience by explaining advanced functions and maintenance tips.
Key Features of the Sony STR-DH590
The Sony STR-DH590 offers 5.2-channel surround sound, 4K/HDR support, Bluetooth connectivity, and multiple HDMI ports, delivering immersive audio and seamless device integration for home theaters.
2.1 5.2 Channel Surround Sound
The Sony STR-DH590 features a 5.2-channel surround sound system, delivering 145W per channel at 1kHz with 6 Ohm impedance. It supports immersive audio formats like Dolby TrueHD and DTS-HD, ensuring rich, detailed sound. This setup enables a cinematic experience with precise speaker placement, enhancing dialogue clarity and spatial audio effects for movies and music.
2.2 4K and HDR Support
The Sony STR-DH590 supports 4K resolution at 60Hz and HDR formats like HDR10, Hybrid Log-Gamma, and Dolby Vision, ensuring vibrant and detailed visuals. It features HDCP 2.2 for 4K content protection. For optimal performance, use Premium High Speed HDMI cables with Ethernet, supporting up to 18 Gbps bandwidth, to enjoy seamless 4K HDR playback from compatible devices.
2.3 Bluetooth Connectivity
The Sony STR-DH590 features built-in Bluetooth, enabling wireless audio streaming from compatible devices. Pairing is straightforward, with the receiver displaying as STR-DH590 during discovery. It supports high-quality audio transmission, making it ideal for streaming music or connecting wireless headphones. Bluetooth connectivity enhances flexibility, allowing seamless integration of mobile devices into your home theater system for convenience and improved entertainment experiences.
2;4 HDMI Inputs and Outputs
The Sony STR-DH590 features 4 HDMI inputs and 1 HDMI output, supporting 4K resolution at 60Hz and HDR formats like HDR10, HLG, and Dolby Vision. HDCP 2.2 ensures compatibility with 4K content. These ports allow seamless connection of devices such as 4K TVs, Blu-ray players, and gaming consoles, providing high-quality video and audio transmission for an immersive home theater experience.
Technical Specifications
The Sony STR-DH590 delivers 145W per channel at 6 Ohms, supports 4K, HDR10, HLG, and Dolby Vision. It features 4 HDMI inputs and 1 output, ensuring high-quality audio-visual performance.
3.1 Power Output and Impedance
The Sony STR-DH590 delivers 145W of power per channel at 1kHz with a 6 Ohm impedance, ensuring robust and clear audio output. This power output supports dynamic range and precise sound reproduction, making it ideal for home theater systems. The impedance rating ensures compatibility with a wide range of speakers, providing balanced and efficient performance across various audio setups.
3.2 Supported Audio Formats
The Sony STR-DH590 supports high-quality audio formats like Dolby TrueHD and DTS-HD, ensuring immersive sound experiences. It also handles PCM, FLAC, and ALAC, delivering crisp and detailed audio reproduction. These formats are compatible with HDMI connections, allowing seamless integration with modern devices for enhanced listening experiences.
3.3 Video Resolution and HDR Standards
The Sony STR-DH590 supports 4K resolution at 60Hz and HDR standards like HDR10, HLG, and Dolby Vision, ensuring vibrant and detailed video output. It also features HDCP 2.2 for 4K content protection. These technologies enable seamless playback of high-definition content from modern devices, delivering an enhanced visual experience for movies and media.
Getting Started with the STR-DH590
Unbox and prepare your Sony STR-DH590 receiver with the included calibration microphone, startup guide, and FM antenna. Begin by connecting speakers and devices, ensuring optimal sound and functionality.
4.1 Unboxing and Supplied Accessories
Inside the box, you’ll find the Sony STR-DH590 receiver, a calibration microphone for accurate speaker setup, a startup guide for quick installation, and an FM antenna for radio connectivity. Additional accessories may include speaker cables and a remote control. Carefully unpack and inventory all items to ensure nothing is missing before proceeding with setup.
4.2 Initial Setup and Connections
After unboxing, turn on the Sony STR-DH590 and connect it to your TV using an HDMI cable. Switch the TV input to the receiver’s HDMI port. Follow the on-screen menu to select your language and configure basic settings. Connect additional devices like Blu-ray players or gaming consoles to the receiver’s HDMI inputs. Ensure all cables are securely plugged in for proper functionality.
Connecting Speakers
Connect your speakers to the Sony STR-DH590 by selecting a 5.1 or 2.1-channel configuration. Place speakers according to the layout guide and secure all cables tightly. Use the calibration microphone for optimal sound setup.
5.1 Speaker System Configuration
A 5.1-channel speaker system includes five full-range speakers (front left, front right, center, surround left, surround right) and a subwoofer. Position front speakers at ear level, angled inward. Place the center speaker below or above the TV. Surround speakers should be slightly above ear level and to the sides or rear of the listening area. Ensure proper cable connections and use the calibration microphone for optimal sound balance.
5.2 Calibrating the Speaker System
Calibrate your speaker system using the provided calibration microphone. Connect the microphone to the CALIBRATION MIC jack and place it in the main listening position. Navigate to the AMP MENU, select Auto Calibration, and follow on-screen instructions. The receiver will measure and adjust speaker levels, delays, and phases for optimal sound balance. Ensure no obstacles block the microphone during calibration.
HDMI Connections and Setup
The Sony STR-DH590 features 4 HDMI inputs and 1 HDMI output, supporting 4K, HDR10, Dolby Vision, and HDCP 2.2. Use high-quality HDMI cables for reliable connections and optimal video quality.
6.1 Connecting HDMI Devices
To connect HDMI devices to the Sony STR-DH590, use the 4 HDMI inputs and 1 output. Connect compatible devices like Blu-ray players or gaming consoles using high-quality HDMI cables. Ensure the HDMI cable supports 4K/60p and HDR for optimal performance. Use the Easy Setup menu to configure HDMI settings and enable features like ARC for seamless audio return channel functionality. Always use Premium High Speed HDMI cables for 4K content.
6.2 HDMI-CEC and ARC Features
The Sony STR-DH590 supports HDMI-CEC, enabling seamless control of connected devices via a single remote. The ARC (Audio Return Channel) feature allows digital audio signals from the TV to be sent back to the receiver through the HDMI cable, eliminating the need for additional audio cables. ARC supports formats like Dolby Digital and DTS, enhancing your home theater experience with simplified connectivity.
Bluetooth Connectivity
The Sony STR-DH590 features built-in Bluetooth, enabling wireless audio streaming from compatible devices. This convenient feature allows seamless connection and high-quality sound without the need for cables.
7.1 Pairing Bluetooth Devices
To pair a Bluetooth device with the Sony STR-DH590, press the Bluetooth input button on the receiver or remote. The receiver will search for nearby devices and display them. Select STR-DH590 on your device to initiate pairing. Once connected, the receiver’s front panel indicator will stop blinking, confirming successful pairing. Ensure your device is in range for a stable connection.
7.2 Troubleshooting Bluetooth Issues
If Bluetooth connectivity fails, reset the receiver and restart your device. Ensure both devices are in range and Bluetooth is enabled. Check for firmware updates and disable other nearby Bluetooth devices; If issues persist, perform a factory reset or consult the Sony STR-DH590 manual for advanced troubleshooting steps.
Audio Calibration and Settings
Use the calibration microphone to optimize speaker settings and balance. Adjust equalization and sound fields to customize your listening experience, ensuring precise audio reproduction for all channels.
8.1 Using the Calibration Microphone
The calibration microphone helps optimize speaker settings for balanced sound. Connect it to the CALIBRATION MIC jack, place it in the main listening position, and run the auto-calibration process. This adjusts delay and level settings for each speaker, ensuring precise audio reproduction. The process typically takes about 30 seconds and is essential for achieving the best sound quality from your system.
8.2 Adjusting Audio Settings for Optimal Sound
After calibration, fine-tune audio settings in the menu to enhance sound quality. Adjust equalizer settings, enable dynamic range compression, or select sound fields like Dolby TrueHD or DTS-HD. These adjustments ensure a balanced and immersive listening experience tailored to your preferences and speaker configuration. Proper settings optimization is key to achieving the best possible audio performance from your STR-DH590 receiver.
Playback and Sound Customization
The STR-DH590 offers versatile playback options and customizable sound settings. Users can play audio from connected devices, adjust sound fields, and optimize settings for enhanced listening experiences.
9.1 Playing Back Audio from Connected Devices
The Sony STR-DH590 enables seamless audio playback from connected devices via HDMI or Bluetooth. Connect Blu-ray players, TVs, or gaming consoles, and use the remote to select the input. Ensure the receiver is set to the correct mode for your device. This setup ensures high-quality audio output tailored to your home theater experience.
9.2 Customizing Sound Fields and Modes
Customize your audio experience with the STR-DH590 by selecting from various sound fields like Dolby TrueHD and DTS-HD. Use the remote to adjust modes for movies, music, or games. Enable Night Mode to reduce dynamic range for quieter environments. This feature ensures optimal sound quality tailored to your content and listening preferences, enhancing your home theater experience.
Troubleshooting Common Issues
Troubleshoot common issues like no sound or distorted audio by checking connections and settings. Refer to the manual for solutions to ensure optimal performance and resolve problems efficiently.
10.1 No Sound or Distorted Sound
If experiencing no sound or distorted audio, check all connections for secure wiring and ensure volume levels are adequate. Verify the input selection matches the connected device and that speaker settings are configured correctly. Inspect cables for damage and ensure HDMI ports are functioning properly. Refer to the manual for detailed troubleshooting steps to resolve sound issues effectively.
10.2 HDMI Connection Problems
If HDMI connections fail, ensure cables are securely connected to both devices and ports. Use High Speed HDMI cables for 4K content. Check TV compatibility with HDCP 2.2 and ensure the receiver’s HDMI settings match the TV. Restart devices to resolve handshake issues. If problems persist, test with another HDMI port or cable to isolate the issue.
Maintenance and Updates
Regularly update the receiver’s firmware for optimal performance. Clean the unit with a soft cloth and avoid harsh chemicals. Refer to the manual for detailed maintenance tips.
11.1 Firmware Updates
Regular firmware updates ensure optimal performance and compatibility. Check for updates via the receiver’s network connection or USB. Updates improve functionality, fix bugs, and enhance device compatibility. Always use a Sony-authorized HDMI cable for reliable updates; Follow the manual’s instructions to avoid interruptions during the update process. Updated firmware ensures the best audio-visual experience for your home theater system.
11.2 Cleaning and Caring for the Receiver
Regular cleaning ensures optimal performance. Use a soft, dry cloth to wipe the exterior and avoid harsh chemicals or liquids. Gently clean HDMI ports with a dry cloth to prevent dust buildup. Avoid exposing the receiver to direct sunlight or moisture. Proper care extends the lifespan and maintains reliable operation of your Sony STR-DH590 receiver.
Warranty and Support
The Sony STR-DH590 is backed by a limited warranty covering manufacturing defects. For assistance, visit Sony’s official website or contact their customer support team for help and repairs.
12.1 Understanding the Warranty
The Sony STR-DH590 comes with a limited warranty that covers manufacturing defects for a specific period. The warranty terms and conditions are detailed in the manual, ensuring repairs or replacements are handled by authorized service centers. Understanding the warranty helps users maintain their receiver’s performance and resolve issues promptly.
12.2 Contacting Sony Support
For assistance with the STR-DH590, users can contact Sony Support through various channels. Visit the official Sony website for regional contact details, email support, or phone assistance. Support is available to address technical queries, repair services, or warranty-related issues. Ensure to have the product’s serial number ready for efficient assistance.
The Sony STR-DH590 manual provides comprehensive guidance for setting up and optimizing your home theater experience. Follow the tips for enhanced sound quality and troubleshooting.
13.1 Final Tips for Using the STR-DH590
Regularly update the firmware for optimal performance. Use high-quality HDMI cables for 4K/HDR content. Position speakers optimally for immersive sound. Refer to the manual for advanced settings. Experiment with sound modes to enhance your listening experience. Reset to factory settings if issues arise. Properly clean and maintain the receiver for longevity. Always consult the manual for troubleshooting guidance and system care.
